Wholesale Lifepo4 Solar Battery (Touch screen selection protocol)
LiFePO4 Solar Battery Product advantages：
- EVE A grade battery cells.
- Touch screen selection protocol
- Multi-language selection
- ISO9001, UL, CEI-21,IEC, CE, UN38.3, MSDS Certificates.
Cooli Lifepo4 Solar Battery 5kwh 10kwh
Touch screen Rack Model LifePO4 Battery
Full new A Grade cells,design life 20 years.
Built-in smart BMS,compatible with more than 30 brands inverter.
With Touch Screen can monitoring the battery data.
Support parallel connection to expand the capacity, up to max 15 units in parallel.
Certifications
Excellent Quality : Use Grade A+ cells quality . Got ISO, UL, CEI-021, IEC, CE, UN38.3, MSDS Certificates.
Lifepo4 Solar Battery
 |
Touch Screen Selection Protocol + Multi-Language Selection + EVE A Grade Battery Cells 1. The battery uses EVE A grade battery cells, which we directly cooperate with and purchase from EVE. 2. The touch screen selection protocol is adopted to realize the convenient replacement of inverter brands, making it compatible with communication. |
|
Touch Screen Selection Protocol + Multi-Language Selection + EVE A Grade Battery Cells 3. The touch screen enables multi-language selection (Chinese, English, Spanish, German, Burmese, Vietnamese, Thai, Indonesian, Italian; etc.) to facilitate customers and users to choose. |
|
Lifepo4 Solar Battery
Rack Lifepo4 Battery 10KWh |
||
| Product specification | 51.2V100Ah | 51.2V200Ah |
| Nominal voltage | 51.2V |
51.2V |
| Nominal capacity | 100Ah |
200Ah |
| Cell type | (LEP) |
(LEP) |
| Standard charge voltage | 58.4V |
58.4V |
| Standrad charge current | [email protected] | 20A |
| Max charge voltage | 100A |
100A |
| Discharge cut-off voltage | 43.2A |
43.2A |
| Max discharge current | 100A | 100A |
| Parallels function | Support 15 units in parallels |
Support 15 units in parallels |
| Communication interface | RS485、CAN (Optional) | RS485、CAN (Optional) |
|---|---|---|
| Cycle life | ≥6000 Cycles (80%DOD) |
≥6000 Cycles (80%DOD) |
| Charge temperature range | 0~60°C | 0~60°C |
| Discharge temperature range | -20~60°C | -20~60°C |
| Dimensions | 484*442*165MM | 474*513*235MM |
| Weight | 53kg | 93kg |
| Installation method | Floor | Floor |
